| Hardware Specification |
| Hardware Version |
3 |
| 10/100Base-T Ports |
8 Auto MDI/MDIX ports |
| Enclosure |
Plastic |
| Dimensions (mm) |
168 x 100 x 29 |
| Weight (g) |
164 |
| Power Requirement (External power adapter) |
DC 5V, 1A |
| Power Consumption / Dissipation (Full operating) |
4.5 Watts / 15 BTU |
| Switch Specification |
| Switch Processing Scheme |
Store-and-Forward |
| Address Table |
2K entries |
| Shared Buffer |
448K |
| Flow Control |
Back pressure Half Duplex, IEEE 802.3x Pause Frame Full Duplex |
| Switch fabric |
1.6Gbps |
| Throughput (packet per second) |
1.19Mpps |
| Standard Compliance |
| Standards Compliance |
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3x (Full-duplex Flow Control) |
| Temperature |
Operating: 0~50 Degree C
Storage: -20~70 Degree C |
| Humidity Operating |
Operating: 5% to 90%, Storage: 5% to 90% (Non-condensing) |
| Regulation Compliance |
FCC Part 15 Class B, CE |
