| Ethernet Connector |
2 x RJ-45( 1 for data + DC out, 1 for Data in) |
| Ethernet Data Rate |
10/100Mbps( vary on Ethernet device attached) |
| Input Voltage |
DC 48V, 0.4A |
| Number of device can be powered |
1 |
| Ethernet Cable |
TIA/EIA-568, Category 5/5e cable |
| LED Indicator |
1 x power, 1 x POE ready / in-use |
| Dimension (W x D x H) |
73 x 55 x 24 mm |
| EMI |
FCC Class B, CE mark |
| Standard Compliance |
IEEE 802.3 Ethernet,
IEEE 802.3u Fast Ethernet,
IEEE 802.3af Power over Ethernet.
|
