| Specificații hardware |
| Porturile de cupru |
8-Port 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| PoE Inject Port |
4-Port with 802.3af / 802.3at PoE injector function (Port-1 to Port-4) |
| Schimbarea arhitecturii |
Store-and-Forward |
| Comutatorul Fabric |
16Gbps/non-blocking |
| Transmitere tranzitorie @ 64 octeți |
11.9Mpps @64 bytes |
| MAC Address Table |
8K entries |
| Tampon de date partajat |
4.1 megabits |
| Controlul debitului |
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex |
| Jumbo Frame |
10KB |
| Butonul de resetare |
< 5 sec: System reboot
> 5 sec: Factory default |
| LED |
Power LED: Power (Green)
PoE Power Usage LED: 30W, 60W, 90W, 120W (Green)
PoE Port(Port-1 to Port-4):
PoE-in-Use (Orange)
LNK/ACT (Green)
10/100/1000BASE-TX Port (Port-5 to Port-8):
1000 (Green)
LNK/ACT (Green) |
| Conector |
■ Removable 3-pin terminal block for power input
- Pin 1/2 for Power (Pin 1: V+ / Pin 2: V-)
- Pin 3 for earth ground
■ DC power jack with 2.0mm central pole |
| Cerinte de putere |
48~56V DC, 3A (max.) |
| Consum de energie / dizolvare |
Max. 152 watts/519 BTU |
| Dimensiuni (L x Î x H) |
148 x 25 x 134 mm |
| Greutate |
532g |
| Protecția ESD |
Contact Discharge 4KV DC
Air Discharge 8KV DC |
| împrejmuire |
Metal |
| Instalare |
Wall mount, magnetic wall mount and DIN-rail kit |
| Putere peste Ethernet |
| PoE Standard |
IEEE 802.3af / 802.3at Power over Ethernet PSE |
| Tip de alimentare PoE |
End-span |
| Putere de ieșire PoE |
IEEE 802.3af Standard
- Per port 48V~56V DC (depending on the power supply), max. 15.4 watts
IEEE 802.3at Standard
- Per port 50V~56V DC (depending on the power supply), max. 36 watts |
| Alocarea pinilor de putere |
1/2(+), 3/6(-) |
| PoE Power Buget |
144 watts (depending on power input) |
| Max. Numărul PD-urilor din clasa 2 |
4 |
| Max. Numărul PD-urilor din clasa 3 |
4 |
| Max. Numărul PD-urilor din clasa 4 |
4 |
| Funcțiile stratului 2 |
| Port Mirroring |
TX/RX/Both
Many-to-1 monitor |
| VLAN |
802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs
802.1ad Q-in-Q tunneling (VLAN stacking)
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
GVRP
Management VLAN |
| Agregarea legăturii |
IEEE 802.3ad LACP and static trunk
Supports 4 groups with 4 ports per trunk |
| Spanning Tree Protocolul |
STP, IEEE 802.1D Spanning Tree Protocol
RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
MSTP, IEEE 802.1s Multiple Spanning Tree Protocol
STP BPDU Guard, BPDU Filtering and BPDU Forwarding |
| IGMP Snooping |
IPv4 IGMP (v2/v3) snooping
IGMP querier
Up to 256 multicast groups |
| MLD Snooping |
IPv6 MLD (v1/v2) snooping, up to 256 multicast groups |
| Lista de control al accesului |
IPv4/IPv6 IP-based ACL/MAC-based ACL
IPv4/IPv6 IP-based ACE/MAC-based ACE |
| QoS |
8 mapping ID to 8 level priority queues
- Port Number
- 802.1p priority
- DSCP/IP precedence of IPv4/IPv6 packets
Traffic classification based, strict priority and WRR
Ingress/Egress Rate Limit per port bandwidth control |
| Securitate |
IEEE 802.1X port-based authentication
Built-in RADIUS client to co-operate with RADIUS server
RADIUS/TACACS+ authentication
IP-MAC port binding
MAC filtering
Static MAC address
DHCP snooping and DHCP Option82
STP BPDU guard, BPDU filtering and BPDU forwarding
DoS attack prevention
ARP inspection
IP source guard
Storm control support
Broadcast/Unknown unicast/Unknown multicast |
| Funcțiile de gestionare |
| Interfețe de management de bază |
Web browser/Telnet/SNMP v1, v2c, v3
Firmware upgrade by HTTP/TFTP protocol through Ethernet network
Configuration upload/download through HTTP/TFTP
Remote/Local Syslog
System log
LLDP protocol
SNTP
PLANET Smart Discovery Utility |
| Interfețe de management securizate |
SSH, SSL, SNMP v3 |
| SNMP MIB |
RFC 1213 MIB-II
RFC 1215 Generic Traps
RFC 1493 Bridge MIB
RFC 2674 Bridge MIB Extensions
RFC 2737 Entity MIB (version 2)
RFC 2819 RMON (1, 2, 3, 9)
RFC 2863 Interface Group MIB
RFC 3635 Ethernet-like MIB |
| Conformitatea standardelor |
| Respectarea reglementărilor |
FCC Part 15 Class A, CE |
| Testul de stabilitate |
IEC 60068-2-32 (free fall)
IEC 60068-2-27 (shock)
IEC 60068-2-6 (vibration) |
| Respectarea standardelor |
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000BASE-T
IEEE 802.3x Flow Control and Back Pressure
IEEE 802.3ad Port Trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP v3
RFC 2710 MLD v1
RFC 3810 MLD v2 |
| Mediu inconjurator |
| De operare |
Temperature: -40 ~ 75 degrees C
Relative Humidity: 5 ~ 95% (non-condensing) |
| Depozitare |
Temperature: -40 ~ 85 degrees C
Relative Humidity: 5 ~ 95% (non-condensing) |
| Accesorii |
| Accesorii standard |
■ Quick Installation Guide x 1
■ 3-pin Terminal Block Connector x 1
■ Wall-mounted Kit x 1
■ DIN-rail Kit x 1
■ Magnet Kit x 1
■ RJ45 Dust Cap x 8 |
